Applications: Type THHN/THWN-2 building wire is intended for general purpose applications as defined by the National Electrical Code (NEC). 6 AWG THHN-THWN-2 is permitted for new construction or rewiring for 600-volt applications. Applications requiring Type THHN or THWN-2, the conductor is appropriate for use in wet or dry locations at temperatures not to exceed 90°C or not to exceed 75°C in oil or coolants. Applications requiring Type AWM conductor is appropriate for use in dry locations at 90°C, or not to exceed 60°C in wet locations or where exposed to oils or coolants. Applications requiring Type AWM conductor is appropriate for use at temperatures to not exceed 105°C in dry locations. Most common building wire used often on sub-panels, hot tubs & jacuzzis.
Also Known As: Copper wire, THWN-2 Wire, building wire, hook up wire, conduit wire, hot tub wire, lighting wire, nylon copper wire, construction cable, 6 gauge wire
Features Nylon outer jacket for easy pulling. VW-1 rated 14 AWG - 6 AWG. All sizes are rated gasoline and oil-resistant II.
Jacket: A tough, polyamide, Nylon outer covering per UL-1063 and UL-83.
Standards: Underwriters Laboratories Standards UL-83, UL-1063, UL-758 AWM Spec 1316, 1317, 1318, 1319, 1320, 1321 ASTM Stranding Class B3, B8, B787 Federal Specification A-A-59544 NEMA WC70/ICEA S-95-658 Institute of Electrical and Electronics Engineers
Constrction: Insulation:Color-coded Polyvinyl Chloride (PVC), heat and moisture-resistant, flame-retardant compound per UL-1063 and UL-8
Specifications: Size:6 AWG Number of Strands:19 PVC Insulation Thickness (Conductor):0.760 mm / 0.030 inches Nylon Jacket Thickness:0.130 mm / 0.005 inches Outside Diameter:6.30 mm / 0.248 inches Weight per Foot: 0.109 lbs Allowable Ampacity:55 Amps at 60℃ / 65 Amps at 75
Yes, we offer free standard shipping on all orders within the United States.
When will I receive my item?
Domestic orders typically arrive within 3-5 business days. Delivery times are estimated and may vary depending on your location, weather conditions, or other unforeseen factors.
Can I change or return my item?
We hope you love your purchase, but if you need to make a change or return your item, we’ve got you covered! You can initiate a return or exchange within 30 days of receiving your order. Please ensure the product is in its original condition and packaging. For more information on our return policy, please visit our Returns & Exchanges page.
Frequently Asked Questions
Q: What applications is the 6 AWG 19-Stranded THHN Black Copper Building Wire suitable for?A: The 6 AWG 19-Stranded THHN Black Copper Building Wire is suitable for general purpose applications as defined by the National Electrical Code (NEC), including new construction and rewiring for 600-volt applications. It can be used in both wet and dry locations and is commonly used for sub-panels, hot tubs, jacuzzis, and other electrical installations.
Q: What are the temperature ratings for this THHN wire?A: This THHN wire is rated for use at temperatures not to exceed 90°C in dry locations and 75°C in wet locations or where exposed to oils or coolants. Additionally, it can withstand up to 105°C in dry locations when used as an AWM conductor.
Q: Is the insulation on the 6 AWG THHN wire moisture and heat resistant?A: Yes, the insulation is made from high heat and moisture-resistant Polyvinyl Chloride (PVC), ensuring durability in various environmental conditions. The nylon outer jacket is also abrasion, moisture, gasoline, and oil resistant.
Q: What is the allowable ampacity for this building wire?A: The 6 AWG 19-Stranded THHN wire has an allowable ampacity of 55 Amps at 60°C, 65 Amps at 75°C, and 75 Amps at 90°C. This makes it suitable for a wide range of electrical loads.
Q: How is the construction of this wire different from standard wires?A: This wire features 19 strands of copper conductors made with annealed, compressed copper, providing flexibility and conductivity. Its nylon jacket and PVC insulation make it more durable compared to standard wires, which may not have the same level of resistance to heat, moisture, and chemicals.
